Adjusting RGBCMY

You can adjust the Hue, Saturation, and Brightness settings for R (red), G (green), B (blue), C (cyan), M (magenta), and Y (yellow) color components.

Turn on all the projectors and select the RGBCMY setting in each projector's Extended menu so that the color tone on the combined screen becomes entirely even.

  1. Press the Menu button.
  2. Select the Extended menu and press Enter.


  3. Select the Multi-Projection setting and press Enter.


  4. Select the RGBCMY setting and press Enter.


  5. Select the color you want to adjust and press Enter. You see this screen:


    • To adjust the overall hue of the color, adjust the Hue setting.
    • To adjust the overall vividness of the color, adjust the Saturation setting.
    • To adjust the overall brightness of the color, adjust the Brightness setting.
  6. Press the left or right arrow buttons to adjust the Hue, Saturation, and Brightness settings.
  7. Repeat the previous three steps as necessary to adjust each color.
  8. Press Menu or Esc to exit the menus.
Parent topic: Using Multiple Projectors (DuoLink)
