| Auto Source Search
|
On
Off
|
Enables the projector to automatically select an input
source; not available in Content Playback mode or
when the projector is turned on in Quick Startup mode |
| Light Source Brightness
Control
|
Maintain Brightness
Maintain Brightness
Level
Light Source Mode
Brightness Level
|
Controls the constant brightness of the projector's
light source
Maintain Brightness:
maintains a constant brightness
Maintain Brightness
Level: selects the brightness level to maintain when the
Maintain Brightness setting is
enabled
Light Source Mode:
selects the brightness mode of the projector when the Maintain Brightness setting is
disabled
- Normal: maximum
brightness
- Quiet: 70%
brightness with reduced fan noise
- Extended: 70%
brightness and extends the life expectancy of the light source
- Custom: select a
custom brightness level and enable use of the next setting
Brightness Level:
select the Custom brightness
level you want |
| Direct Power On
|
On
Off
|
Controls whether the projector automatically turns on
when you plug it in |
| Auto Power On
|
HDMI1
Computer1
USB Display
Off
|
Selects whether to automatically turn on the projector
when you connect an input signal to a specific input source |
| Power On Trigger
|
Plug-in Detection
Signal Detection
|
Selects the power on condition when Auto Power On is set to HDMI1:
- Plug-in Detection:
automatically turns on the projector when the device connected to
the HDMI1 port is turned on
- Signal Detection:
automatically turns on the projector when it detects an HDMI video
signal on the HDMI1 port;
selecting this option increases standby power consumption
|
| Sleep Mode
|
On
Off
|
Automatically turns off the projector after an interval
of inactivity |
| Sleep Mode Timer
|
1 to 30 minutes |
Sets the time before the projector automatically turns
off (Sleep Mode must be turned
on) |
| A/V Mute Timer
|
On
Off
|
Automatically turns off the projector after 30 minutes
of inactivity |
| Lens Cover Timer
|
On
Off
|
Automatically turns off the projector after 30 minutes
if the lens cover is closed. |
| Standby Mode
|
Communication On
Communication Off
|
Enable this setting to allow monitoring and control of
the projector over a network when the projector is in standby mode.
This setting is only displayed in the following
cases:
- A/V Output is set
to While Projecting in the Signal
I/O menu
- Auto Power On is
not set to HDMI1 and Power On Trigger is set to Plug-in Detection
- Auto Power On is
set to Off in the projector's
Network menu, or
- USB Power is set
to On While Projecting.
|
| Port
|
Wired LAN
Wireless LAN
|
Selects the port to use while the Standby Mode setting is set to Communication On |
| Startup Source
|
Various input sources available |
Selects the source displayed on startup in Content
Playback mode |
| Quick Startup
|
Off
20min.
60min.
90min.
|
Sets the time period for which you want to be able to
restart the projector within five seconds of turning it off (Quick
Start mode).
It may take longer than five seconds when projecting
from the projector's USB port or when using the Screen Mirroring
features.
This setting is only displayed when:
- A/V Output is set
to While Projecting in the
projector's Signal I/O menu
- Auto Power On is
set to HDMI1 and Power On Trigger is set to Plug-in Detection in the projector's
Operation menu, or
- Auto Power On is
set to Off in the projector's
Network menu
|
| USB Power
|
On While Projecting
Always On
|
This setting is only displayed when:
- A/V Output is set
to While Projecting in the
projector's Signal I/O menu
- Auto Power On is
set to HDMI1 and Power On Trigger is set to Plug-in Detection in the projector's
Operation menu, or
- Auto Power On is
set to Off in the projector's
Network menu
|
| Closed Caption
|
CC1
CC2
Off
|
Selects the type of closed captioning to display
(availability varies by country) |
| Indicators
|
On
Off
|
Enables or disables the status indicator lights on the
projector |
| Content Playback
|
On
Off
|
Enable to play back a playlist created in the Epson
Projector Content Manager software |
| Overlay Effect
|
Overlay Effect
Shape Filter
Color Filter
Lightness
|
Adds color and shape effects to the projected image;
not available when Edge Blending
is enabled |
| USB Viewer
|
— |
Select a playlist from the USB device |
| Reset Operation
Settings
|
— |
Reset all settings on the Operation menu to their
default values |
