| Projector ID
|
Off
1 through 9
|
Assigns an ID for the projector when you use multiple
projectors |
| Tiling
|
Column
Column Order
|
Sets the number of split screens and the position of
each projected image for a tiled setup |
| Geometry Correction
|
Quick Corner
Arc Correction
Point Correction
Correct Distortion Using
Smartphone
Fit to Screen Using
Smartphone
Memory
|
Adjusts image shape to rectangular (horizontally and
vertically)
Quick Corner: select
to correct image shape and alignment using an on-screen display
Arc Correction:
select to adjust the curve or arc of the horizontal and vertical
sides
Point Correction:
select to divide the projected image into a grid and correct
distortion by moving a selected point
Correct Distortion Using
Smartphone: corrects the distortion of projected images
using the Epson Setting Assistant app
Fit to Screen Using
Smartphone: corrects the shape and position of images to fit
on your screen using the Epson Setting Assistant app
Memory: controls
memory functions for current image shape settings
- Save Memory: saves
the current image shape as a memory setting
- Load Memory: loads
a saved image shape memory
- Rename Memory:
renames a saved image shape memory
- Erase Memory:
deletes a saved image shape memory
- Reset Memory:
resets all the image shape memory settings
|
| Edge Blending
|
Edge Blending
Top Edge
Bottom Edge
Left Edge
Right Edge
Line Guide
Pattern Guide
Guide Color
|
Blends the border between multiple images to create a
seamless screen |
| Black Level
|
Color Adjustment
Area Correction
Reset
|
Adjusts the brightness and tone differences in
overlapping images. This setting is only displayed when
Blending is set to On for the Top
Edge, Bottom Edge,
Left Edge, or Right Edge setting. |
| Scale
|
Varying levels available |
When using multiple projectors, adjusts the scale of
the image displayed by each projector |
| Color Uniformity
|
Color Uniformity
Adjustment Level
Start Adjustments
Reset
|
Adjusts the color tone balance
Color Uniformity:
set to On to adjust the color
tone balance for the whole screen
Adjustment Level:
sets the adjustment level
Start Adjustments:
adjusts the red, green, and blue color tones individually for the
selected area
Reset: resets all
Color Uniformity adjustment values to their defaults |
| Light Source Mode
|
Normal
Quiet
Extended
Custom
|
Selects the brightness mode of the projector when the
Maintain Brightness setting is
disabled
Normal: maximum
brightness
Quiet: 70%
brightness with reduced fan noise
Extended: 70%
brightness and extends the life expectancy of the light source
Custom: select a
custom brightness level and enable use of the next setting |
| Color Matching
|
Adjustment Level
Red
Green
Blue
Brightness
|
Corrects the tint and brightness differences between
images |
| RGBCMY
|
Varying levels available |
Adjusts the hue, saturation, and brightness for each
color |
| Reset Multi-Projection
Settings
|
— |
Resets all settings on the Multi-Projection menu to their default
values |
