Zooming Into Images (E-zoom)

You can zoom the projected image using the E-Zoom button on the remote control.

The size and the position of the zoomed image remain even after switching the input source or turning off the projector.

  1. Press the E-Zoom + button on the remote control.

    The projected image is enlarged focusing around the center of the image. You can enlarge the image between one to four times in 25 incremental steps.

  2. Use the following buttons on the remote control to adjust the zoomed image while the zoom ratio is displayed:

    • Press the E-Zoom + button repeatedly to zoom into the image.

    • To pan around the zoomed image, use the arrow buttons.

    • To zoom out of the image, press the E-Zoom – button.

    • To return to the original image size, press the Esc button.

When projecting images from an Epson document camera, you can enlarge the image from one to eight times its size in 57 incremental steps using the E-Zoom + button on the document camera.

When the zoom ratio display disappears, the size and the position of the zoomed image will be saved. Press the E-Zoom +/- buttons to make adjustments again.
