You can attach a safety wire to your projector for increased safety as shown.
Before you start, you need to remove the front adjustable feet and the rear adjustable foot from the projector. Also, make sure you have securely attached the ELPMB22 ceiling mount to the projector and have the following items that are included in the safety wire set:
Safety wire × 1
Carabiner × 2 (Only one carabiner is used for the ELPMB22.)
Wire clamp × 1
Attaching screw (M4 × 10 mm) × 1
For details on installing the ELPMB22, see the Ceiling Mount ELPMB22/ELPMB23 Instruction Manual.
Attach the wire clamp to the carabiner, and then use the screw to
fix the wire clamp to the wire clamp fixing point () on the projector.
Loop the safety wire around the support shaft of the ceiling mount, and attach both ends to the carabiner on the projector.
Tighten the carabiner lock.
