When Using the Setting Plate ELPMB75

You can attach a safety wire to your projector for increased safety as shown.

Before you start, you need to remove the front adjustable feet and the rear adjustable foot from the projector. Also, make sure you have securely attached the ELPMB75 setting plate to the projector and have the following items that are included in the safety wire set:

  • Safety wire × 1

  • Carabiner × 2

  • Wire clamp × 1

  • Attaching screw (M4 × 10 mm) × 1

For details on installing the ELPMB75, see the ELPMB75 User's Guide.

  1. Attach the wire clamp to the carabiner, and then use the screw to fix the wire clamp to the screw into the wire clamp fixing point () on the projector.

  2. Loop both ends of the safety wire through the carabiner, and then tighten the carabiner lock.

  3. Pass the other carabiner through the hole in the arm of the setting plate.

  4. Loop the safety wire through the carabiner attaching it to the setting plate.

  5. Tighten the carabiner lock.
