Connecting to a Computer for VGA Video and Audio

You can connect the projector to your computer using a VGA computer cable.

You can play sound through the projector's speaker system by connecting a commercially available 3.5 mm stereo mini-jack audio cable.

  • To connect a computer that does not have a VGA video port, you need an adapter that allows you to connect to the projector's VGA video port.

  • You can also set the port used for audio input in the projector's Extended menu.

    Extended > A/V Settings > Audio Settings > Audio Output

  • Make sure the audio cable is labeled "No resistance".

  1. Connect the VGA computer cable to your computer's monitor port.

  2. Connect the other end to a Computer port on the projector.

  3. Tighten the screws on the VGA connector.

  4. Connect the audio cable to your laptop's headphone or audio-out jack, or your desktop's speaker or audio-out port.

  5. Connect the other end to the Audio port that corresponds to the Computer port you are using.
