Connecting to an HDMI Video Source

If your video source has an HDMI port, you can connect it to the projector using an HDMI cable and send the image source's audio with the projected image.

Attention

Do not turn on the video source before connecting it to the projector. Doing so could damage the projector.

  1. Connect the HDMI cable to your video source's HDMI output port.

  2. Connect the other end to the projector's HDMI port.

If you have problems hearing audio through the HDMI connection, connect one end of a commercially available 3.5 mm stereo mini-jack audio cable to the projector's Audio port and the other end to your video source's audio out port. Select the audio input port you connected to in the projector's Extended menu. (Available only for models that have the Audio port.)

Extended > A/V Settings > Audio Settings > HDMI Audio Output
