Connecting to an External HDMI Monitor

You can connect an external HDMI monitor to the projector's HDMI Out port and use it to display images from the current input source.

  • If the audio from the projector and HDMI monitor is out of sync, mute the audio on either the projector or the HDMI monitor.

  • If the output image does not appear on the HDMI monitor, change the EDID settings in the projector's Signal I/O menu to match the resolution of the HDMI monitor.

  • Use an HDMI monitor that supports HDCP2.3.

  • The HDMI Out port is not guaranteed to operate for all monitor devices and products.

  1. Connect the HDMI cable to your monitor's HDMI input port.

  2. Connect the other end to the projector's HDMI Out port.
