Connecting to External Speakers

You can connect the projector to external self-powered speakers. You can control the volume using the projector's remote control.

To output audio from external speakers, set the Audio Out Device setting to Projector in the projector's Signal I/O menu. When an audio/video system is not connected to the projector, audio is output from the external speakers even if Audio Out Device is set to AV System.

Signal I/O > HDMI Link > Audio Out Device

  • If you want to output audio from the external speakers when the projector is turned off, set the following items in the projector's Operation menu:

    • Select Normal as the Standby Mode setting

    • Select On as the Standby Audio Output setting

  • You can also connect the projector to an amplifier with speakers.

  • The projector's built-in speaker system is disabled when you connect external speakers.

  1. Make sure your computer or video source is connected to the projector with both audio and video cables as necessary.

  2. Locate the appropriate cable to connect your external speakers, such as a stereo mini-jack-to-pin-jack cable, or another type of cable or adapter.

  3. Connect one end of the cable to your external speakers as necessary.

  4. Connect the stereo mini-jack end of the cable to your projector's Audio Out port.
